Deck BRINE TRAP
Wood ground Drain Brine
--- ใช้เพื่อการศึกษาเท่านั้น---
งานห้องสมุด ศูนย์ฝกพาณิชย์นาวี
To bilge
Side frame Wood ground bolted to frame Side shell Fibreglass or foam slabs 50 mm air gap
ึ 150 mm × 75 mm pitch pine grounds at 400 mm centres Insulation details FIGURE 28.3
Galvanized mild steel or aluminium lining 37 mm T&G Kerung hardwood
Side shell screwed to wood grounds
Insulation 25 mm T&G softwood Tank top oil tank under
PLAN
