Page 263 - Ship Construction.DJ Eyres 6Ed

Ch22-H8070.fm Page 252 Wednesday, October 18, 2006 6:59 AM

Sheerstrake 1500 mm × 12.5 mm Side shell (10.5 mm)

--- ใช้เพื่อการศึกษาเท่านั้น---
Deck plating (11 mm) Stringer Bottom plating (11 mm)
งานห้องสมุด ศูนย์ฝกพาณิชย์นาวี

Trunk plating (11 mm) Flat stiffener Longitudinal Frame space in way of transverse Transverse

bulkhead
ึ Keel plate 1075 mm × 16.5 mm Midship section of coastal tanker of less than 5000 tonnes deadweight with trunk.

175 mm × 8.5 mm Stringer Docking bracket

Stiffener Frame space clear of transverse

Deck and trunk longitudinals 200 mm × 12.5 mm Bracket Stringer Bracket Bottom longitudinals 250 mm × 12 mm FIGURE 22.1

Side frame 175 mm × 8.5 mm
