Shell Plating and Framing 185
Rounded sheerstrake Hatch coaming L
(21.75 mm, grade ‘E’) Deck plating
(21.75 mm, grade ‘D’)

Longitudinals (250 mm × 22 mm O.B.P.)
Longitudinals (200 mm × 975 mm O.B.P.) Tank plating (10.5 mm)
--- ใช้เพื่อการศึกษาเท่านั้น---

งานห้องสมุด ศูนย์ฝกพาณิชย์นาวี

Bracket

Length B.P. 141 m
Beam mid. 20.5 m
Depth mid. 12.05 m
Side frame
(250 mm × 11 mm O.B.P.)

Shell plating (150 mm)
ึ

Hopper plating (15.5 mm)

Longitudinals as double bottom
Inner bottom longitudinals 225 mm × 11 mm O.B.P.
Tank top (15.5 mm)

Pipe
tunnel

Bottom plating (14 mm)
Stiffener Keel plate
Bottom longitudinals
225 mm × 11 mm O.B.P. (1345 mm × 22.5 mm)
Figure 17.7 Bulk carrier – single side skin midship section
