Resulting pull out INADEQUATE CROSS-SECTION Small spherical cavities called ‘porosity’ Root not properly back gouged
Lamellar tear in non-metallic stringer UNDERBEAD CRACKING GAS ENTRAPMENT Long cavities called ‘pipes’ SLAG INCLUSIONS Inclusions between weld passes not cleaned out
--- ใช้เพื่อการศึกษาเท่านั้น---
LAMELLAR TEARING
งานห้องสมุด ศูนย์ฝกพาณิชย์นาวี
CRATER CRACKS
ึ Weld faults
FIGURE 10.5
EXCESSIVE REINFORCEMENT
OVERLAP UNDERCUT LACK OF REINFORCEMENT LACK OF PENETRATION LACK OF FUSION
